CNC Turning- and Milling Center

MORI SEIKI NT 3200 DCG / 1000 SZ

turning diameter 600 mm
turning length 1.045 mm
control MSX - 711 III MAPPS III
swing diameter over support 600 mm
distance between spindles 1.255 mm
max. bar capacity 65 mm
turning speed range - main spindle max. 5.000 min/-1
power capacity - main spindel 25 / 22 kW
no. of turning speeds 2
spindle nose JIS A2-6
spindle bore 73 mm
internal diameter 120 mm
Dodpfx Acez At T Hjfecp
C-Axis 0,0001 °
chucking diameter 200 mm
Speed range Tool Spindle max. 12.000 min/-1
Power rating Tool Spindle 5,5 / 3,7 kW
tool taper Capto C5
internal diameter 65 mm
B - Axis 0,0001 °
swivellable +/- 120 °
x-axis 685 (610 + 75) mm
y-axis +/- 125 mm
z-axis 1 mm
number of toolpositions 12 pos.
Shank height for square tool 20 mm
Drill shank diameter max. 32 mm
tools in tool magazin 40 pos.
max. tool diameter 70 mm
max. tool-dia with free toolbox 125 mm
max. tool length 300 mm
max. tool weight 4 kg
change-time tool to tool 1,25 sec
Rapid traverse X / Z: 50 m/min
Rapid traverse Y: 30 m/min
Rapid traverse X2 / Z2: 30 m/min
total power requirement 88 kVA
weight of the machine ca. 16,5 t
dimensions of the machine ca. 6,0 x 4,0 x 3,0 m
High-Precision 5 Achsen CNC-Turning- and Millingcenter
MORI SEIKI - NT 3200 DCG / 1000 SZ

- 5 Axis
- Swivable Milling-Head (B-Axis)
- Subspindle
- lower turret

- approx. 11,300 power-on hours
- approx. 9,200 spindle hours
